| Basic performance |
Oil capacity |
| Operating weight of the whole machine (kg) |
23698 |
Fuel tank (L) |
380 |
| Bucket capacity (m³) |
3.4-4.2 |
Hydraulic tank (L) |
110 |
| Maximum unloading height (mm) |
3005 |
Coolant (L) |
39 |
| Rated deadweight (ton) |
More than 6 tons |
Gearbox |
| Engine |
Speed 1 gear (km/h) |
6.7/7.4 |
| Engine type |
Caterpillar Cat C11 ACERT |
Speed 2 gears (km/h) |
12.6/13.9 |
| Displacement (L) |
11.1 |
Speed 3 (km/h) |
22.1/24.3 |
| Rated power (kw/rpm) |
195kw |
Speed 4 gears (km/h) |
37.4 |
| Cylinder diameter × stroke (mm) |
130 x 140 |
Body size |
| Operation time of working device |
Total length of transport (mm) |
12040 |
| Lift (s) |
5.9 |
Total transport width (mm) |
3580(3082 when contracted) |
| Unloading (s) |
1.6 |
Total transport height (mm) |
3660 |
| Lower empty bucket (s) |
2.4 |
Full cab height (mm) |
3285 |
| Ternary sum (s) |
9.9 |
Track grounding length (mm) |
4020 |
| Technical parameter |
Total track length (mm) |
5055 |
| Distance from rear axle to hinge point (mm) |
1725 |
Track plate width (mm) |
600 |
| Tipping load (kg) |
15474 |
Total track width (mm) |
3490(2992 when contracted) |
| Scope of operation |
Track gauge (mm) |
2890(2392 at contraction) |
| Maximum excavation radius (mm) |
12005 |
Minimum ground clearance (mm) |
555 |
| Maximum excavation radius of stop surface (mm) |
11800 |
Counterweight ground clearance (mm) |
1320 |
| Maximum digging depth (mm) |
7790 |
Back end turning radius (mm) |
3605 |
| Maximum excavation height (mm) |
10925 |
Overall size |
| Maximum unloading height (mm) |
7625 |
Minimum ground clearance (mm) |
496 |
| Maximum vertical digging depth (mm) |
6600 |
Bucket width (mm) |
3145 |
| Hydraulic system |
|
