| Item | Data | Item | Data |
| Max.Design Weight（kg） | 108000 | Overall Dimension（LxWxH）（mm） | 9770x4230x4560 |
| Unladen/Laden Max.Speed（km/h) | 48/41 | Unladen/Laden Max.Gradeability（°） | 36.7 |
| Struck Capacity (flat/ heaped)m³ | 38/44 | Min.Turning Diameter(m) | ≤24 |
| Curb Weight（kg） | 39000 | Payload(kg) | 70000 |
| Wheel Tread（mm） | Front Axle：3120；Middle-Rear Axle：2910 | Wheelbase（mm） | 3910（Front-Middle）1800（Middle-Rear） |
| Approaching Angle(°） | 31 | Departure Angle（°） | 60 |
| Ground Clearance（mm） | ≥466 /406 | Number of Axles | 3 |
| Make | Weichai WP13G530E310 | Number of Cylinder | 6 |
| Type | Line, Direct Injection, Water-cooling, Inter-cooling, Electric-controlled | Bore/Stroke（mm） | 127/165 |
| Rated Power(kW) | 390 | Min. Fuel Consumption（g/kW.h) | 195.9 |
| Rated Speed(r/min) | 2100 | Max. Torque（N.m) | 2300 |
| Emission load (ml) | 12540 | Emission Standard | StageIII GB20891-2014 |
| Auto Gearbox FC6A250PRT |
Type | planetary | |
| Speed Ratio | 1st | 4.4 | |
| 2nd | 2.33 | ||
| 3rd | 1.53 | ||
| 4th | 1.00 | ||
| 5th | 0.72 | ||
| 6th | 0.61 | ||
| R1 | 3.97 | ||
| Front Axle | Steering Axle | Welded Axle Housing | |
| Middle-Rear Axle | Main Reduction Ratio | 4.11 | |
| Wheel Edge Reduction Ratio | 4.952 | ||
| Total Reduction Ratio | 20.357 | ||
| Wheel | Rim | 13.00/2.0-25 | |
