Description | Unit | Parameter value |
Rated operating load | kg | 3000 |
Bucket capacity | m³ | 1.5~2.5 |
Machine weight | kg | 10600±200 |
Dump clearance at maximum lift | mm | 2770~3260 |
Reach at maximum lift | mm | 1010~1210 |
Wheel base | mm | 2600 |
Tread | mm | 1850 |
Height of hinge at maximum lift height | mm | 3830 |
Working height(fully lifted) | mm | 4870 |
Max.breakout force | kN | 130 |
Max.horse power | kN | 95 |
Hydraulic cycle time-raise | s | 5.5 |
Total hydraulic cycle time | s | 10 |
Min. turning radius over tyres | mm | 5165 |
Articulation angle | ° | 35±1 |
Gradeability | ° | 28 |
Tyre size | 17.5-25-12PR | |
Overall machine dimension L×W×H | mm | 7050×2482×3118 |
Model | WP6G125E22 | |
Emission standards | Emission 2 | |
Rated Power/Speed | kW/rpm | 92/2200 |
Fuel Tank | L | 170 |
Hydraulic Tank | L | 170 |
Ⅰ-gear(F/R) | km/h | 8/10 |
Ⅱ-gear(F/R) | km/h | 13/30 |
Ⅲ-gear(F) | km/h | 24/- |
4-gear(F) | km/h | 40/- |
