New&Used Doosan Construction Excavator

Description

This Doosan Construction is fully equipped, including a newly designed engine, a spacious and comfortable cab, and a multifunctional operator interface. It features an efficient hydraulic system, durable construction and advanced automation for superior performance and operator experience. The advantage lies in multiple working modes, fast working speed and excellent energy management function. This Doosan Construction is suitable for the needs of various construction environments, and is the first choice for engineering projects such as construction sites, road construction, land development, and mining.

Parameter

Specifications

Operating weight	21800kgs
Bucket Volume	0.93m³
Engine	Mitsubishi direct injection engine
Turning speed (rpm)	11
walking speed(km/h)	5.4/3.3
Maximum climbing ability(%)	70/35°
Ground pressure(Kpa)	46.5
Bucket digging power(KN)	138
Bucket rod digging force(KN)	103
Rated power(kw/rpm)	114/2050
Cooling system	water cooling
Set pressure for main overflow(Mpa)	34.3
Maximum flow of main pump(l/min)	2*210
Traveling hydraulic circuit(Mpa)	34.3
Rotary hydraulic circuit(Mpa)	25.5
Control hydraulic circuit(Mpa)	3.9
Length(mm)	9680
Width(mm)	2980
Height(mm)	3440
Total length of track(mm)	4250
The width of crawler plate(mm)	600
Total width of track(mm)	2980
Gauge of tracks(mm)	2380
Min ground clearance (mm)	440
Minimum turning radius of front working device(mm)	3595
Back-end radius of gyration(mm)	2890
Max digging ridius(mm)	9950
Maximum excavation radius of stop face (mm)	9885
Maximum excavation depth (mm)	6600
Maximum excavation height (mm)	9570
Maximum unloading height (mm)	6700
Maximum vertical excavation depth (mm)	5800
