| SPECIFICATIONS FOR CATERPILLAR 345D CRAWLER EXCAVATOR | |||
The machine type |
Moving type | Crawler | |
| Type | Large | ||
| Digging way | Back shovel | ||
Engine |
Engine model | CAT C13 ACERT | |
| Number Of Cylinders | 6 | ||
| Rated power | KW (HP) | 283 | |
| Rated speed | RPM | 1900 | |
| Displacement | L | 12.5 | |
| Manafacture | Caterpillar | ||
Main performance parameters |
Bucket capacity | M³ | 1.8-3.5 |
| Maximum Digging Heigh | MM | 8010 | |
| Maximum Digging Depth | MM | 6220 | |
| Max Digging Radius | MM | 11631 | |
| Working speed | KM/H | 2.8-4.5 | |
| Operating Weight | KG | 45375 | |
