| Item | Unit | Value | Remarks | |
| Working performance | Max. rated lifting capacity | kg | 30000 | |
| Max. load moment of basic boom | kN.m | 1132 | ||
| Max. load moment of main boom(fully extended) | kN.m | 617.5 | ||
| Max. load moment of basic boom | m | 11.1 | ||
| Max. lifting height of main boom | m | 40.5 | The parameters do not include deflection of main boom and jib | |
| Max. lifting height of jib | m | 48.5 | ||
| Working speeds | Max. hoist rope speed(Main winch) | m/min | 120 | At the 4th layer |
| Max. hoist rope speed(Auxiliary winch) | m/min | 100 | At the 2nd layer | |
| Boom demrricking up time | s | 40 | ||
| Boom demrricking up time | s | 80 | ||
| Slewing speed | r/min | 0 – 2.2 | ||
| Driving parameters | Max. driving speed | km/h | 78 | |
| Max. gradeability | % | 37 | ||
| Min turning diameter | m | ≤22 | ||
| Min. ground clearance | mm | 220 | ||
| Oil consumption per hundred kilometers | L | 35 | ||
| Mass | Deadweight in driving condition | kg | 32000 | |
| Complete vehicle kerb mass | kg | 31870 | ||
| Front axle load | kg | 7000 | ||
| Rear axle load | kg | 25000 | ||
| Dimensions | Overall dimensions(L×W×H) | mm | 12900×2500×3465 | |
| Longitudinal distance between outriggers | m | 5.36 | ||
| Transversal distance between outriggers | m | Fully extended:6.10 m | ||
| Intermediately extended:4.20 m | ||||
| Tail slewing radius | mm | 3385
