| Product Name | DFL5250GJBA-K09F-100-002J | ||||
| Type | 6x4 Chassis | ||||
| Chassis Dimensions(mm) | The picture is just for reference. | ||||
| Overall chassis length | 8090 | ||||
| Cab width | 2500 | ||||
| Cab height (unladen) | 3030 | ||||
| Wheel base | 3800+1350 | ||||
| Front overhang | 1460 | ||||
| Rear overhang | 1480 | ||||
| Chassis weights(kg) | |||||
| G.V.W | 25000 | ||||
| Curb weight(chassis) | 8500 | ||||
| Frame profile Dimensions(mm) | |||||
| Frame width (front ) | 860 | ||||
| Frame width ( rear ) | 860 | ||||
| Section height | 300 | ||||
| Section width | 90 | ||||
| Engine | Type | Dongfeng Cummins L340 30 | |||
| Emission level | Euro Ⅱ | ||||
| Maximum power | 250 kw at 2200 rpm | ||||
| Maximum torque | 1350 Nm at 1400 rpm | ||||
| Number of cylinders | 6 | ||||
| Displacement (lit) | 8.9 | ||||
| Cylinder bore (mm) | 114 | ||||
| Stroke (mm) | 145 | ||||
| System | Water cooled,turbocharged ,Air cooled ,with EGR，Power taken off from engine. | ||||
| Clutch | Type | CHINA | |||
| Plate's diameter | ¢430mm | ||||
| operating system | Hydraulic control with air booster, pulling | ||||
| Gear box | Type | 9JS150T-B DD | |||
| Number of gears | 9 forward gears & 1 reverse | ||||
| Ratios | 12.65；8.38；6.22；4.57；3.40；2.46；1.83；1.34；1.00;13.23(R) | ||||
| Brake System | Full air brake system, split pneumatic circuit ； parking spring brake acting on rear axles , exhaust brake. | ||||
| Cab | Sleeper cab,forward control type,low roof,new face, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension , adjustable driver’s seat, air conditioning system. D310 |
||||
| Axle | Front | Elliot type, I beam section | |||
| Load capacity(ton) | 7 | ||||
| Rear | Single reduction ,with axle lock , ratio 5.571 | ||||
| Load capacity(ton) | 26 | ||||
| Tyres | 11.00-20 | ||||
| Suspension | Front | 8- Leaf spring with shock absorber | |||
| Rear | 12-leaf spring | ||||
| Battery | Voltage (V) | 24 | |||
| Battery capacity (A.h) | 165X2 | ||||
| Fuel | Type | Steel fuel tank, with lockable cap | |||
| Capacity | 200lit | ||||
| Model | 10m3 Special function device of mixer | ||||
| Overall Dimensions | 7030*2500*2720mm | ||||
| Curb Weight | 4850kg | ||||
| Matched Chassis Type | Driving type 6*4,Wheel base3825+1350. Engine backend with full power PTO. | ||||
| Tank Capacity (m3) | 10 | ||||
| Ttank geometric capacity (m3) | 16 | ||||
| Tank Material | Q345，The cylinder wall thickness 5mm, The head wall thickness 6mm | ||||
